EGG QUAIL - Seat Unit Operations; Operating the Parking Brake; Adjusting the Seat Backrest; Removing and Fitting the Seat Unit

9
8
Section 2 - Seat Unit.
8. Adjusting the seat backrest.
Lift the adjustment handle on the top side of the
seat back and adjust the backrest to the desired
position.
NB: The seat unit has 3 positions
9. Removing and fitting the seat unit to the
chassis.
To remove the seat unit, fold the seat back and
seat base together so that they are approximately
vertical and keep hold of the seat back with your
left hand.
9a. Hold on to the right-hand side central hub and
position your thumb on the lever. Rotate the seat
unit backwards with your left hand so that it is
resting against your forearms and position your
left hand over the other central hub release lever.
6. Operating the parking brake
Press down on the pedal to engage the parking
brake. Press down and release to disengage the
parking brake.
WARNING: Never leave the vehicle without first
fully engaging the parking brake.
7. Adjusting the handle height.
Rotate the central section of the handle forward
and slide the handle up or down into one of the 5
available positions.
6
7 9
9a
8
P
RESS
DOWN
FOLD
BACK
LIFT
ROTATE
