56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2100SP & LM2100
26
6. While wearing protective gloves, remove the bolt, outer
ange and the blade (Fig. 24).
INSTALLING THE BLADE
WARNING: Always protect your hands by wearing heavy
gloves or wrapping the cutting edges with rags or other materials
when performing any maintenance on the mower blade.
Always remove the battery pack when servicing or transporting
the mower.
NOTICE: To re-install or replace the blade, be sure to replace the
parts in the exact order in which they were removed (Fig. 24).
1. Mount the inner ange to the fan (Fig. 25).
2. Mount the fan and the inner ange onto the motor shaft
with the fan blade towards the deck (Fig. 26).
24
Fan
Inner ange
Bolt
Outer ange
Blade
THIS SIDE FACING GRASS
25
26
Fan blade
Inner ange
Fan
