56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 19
ASSEMBLING THE GRASS BAG
1. Check the grass bag before
assembling, to make sure that there
is no damage.
2. Slide the grass bag onto the frame,
as shown in Fig. 2.
3. Assemble the top clips to the frame,
as shown in Fig. 3, then assemble
the two side clips. Assemble the
bottom clip last.
4. The completely assembled grass
bag is shown in Fig. 4.
2
3
4
