EGO EG0800 - Specifications

EARTH/ICE AUGER — EG0800/EG0800-FC/IG0800/IG0800-FC12
SPECIFICATIONS
Model Number EG0800/EG0800-FC IG0800/IG0800-FC
Voltage 56 V
56 V
Torque 65 ft-lb (88 Nm) 65 ft-lb (88 Nm)
Auger Bit/Hole Diameter 8 in. (200 mm) 8 in. (200 mm)
Maximum Drilling Depth 32 in. (800 mm) 39 in. (990 mm)
No-load
Speed (n
0
)
Forward
Low: 0-150 /min (RPM)
High: 0-210 /min (RPM)
Low: 0-150 /min (RPM)
High: 0-210 /min (RPM)
Reverse 100 /min (RPM) 100 /min (RPM)
Weight (Without battery pack) 34.2 lbs (15.5 kg) 29.8 lbs (13.5 kg)
Ingress Protection Rating IPX4* (Protection from splashing water)
Recommended Operating
Temperature
-4°F – 104°F (-20°C – 40°C)
Recommended Storage
Temperature
-40°F – 158°F (-40°C – 70°C)
* NOTE: IPX4 rating is based on the machine and battery being used together as a
system.
