56V LITHIUM-ION CORDLESS BLOWER — LB5800 15
ASSEMBLING THE BLOWER
TAPERED/FLAT NOZZLE
1. Remove the battery.
2. Align the groove in the tapered
nozzle with the knob on the
tube. Push the nozzle onto the
tube until it snaps into place
(Fig. 5 & 6).
3. To remove the tapered nozzle,
press and hold the nozzle-
release button to disengage
the latch, then pull the nozzle
straight from the blower (Fig. 7).
Follow the same sequence to
assemble or remove the at
nozzle.
5
6
7
2
1
