22
Electric
contact
base
Spring
Sliding block
Release button
Electric contact base
Description Part Number Description Part Number
Release button 3126760001 Electric contact base 3126782001
Sliding block 3126772001 Main PCBA
2830176002
Spring 3660303002 Electric contact of the PCBA
2830223001
3. Main PCBA Replacement
LM2020E-SP Lawn Mower
10. Main PCBA, electric contact of the PCBA and electric contact base are shown as below. If
any part is damaged or missing, replace it as needed.
Main PCBA
Electric contact
of the PCBA
To Next Page
