When opening the switch box covers, the following relevant parts can be replaced:
Description Part Number
Main Switch 4870566001
Main Switch Trigger 3127908001
Main Switch Lever 2824118001
Switch ASSY 2824754003
Self-propelled Lever 3127928001
Switch Actuator 3127905001
Safety Button 3127929001
Top Handle 2823782001
Self-propelled Speed-adjusting
PCB
4890439003
Self-propelled Speed-adjusting
Knob
3127930001
Top & Bottom Switch Box Set 2824305001
3
Top Handle & Switch Box Cover Replacement
LM2020E-SP Lawn Mower
REMARK: The 1pc plain washer and 1pc
spring, which are used to fix the switch
actuator will be improved, combined
into 1pc conical spring in order to avoid
spring missing during mower operation
(see P?).
REMARK: Self –propelled switch and speed-adjusting PCB single replacement will be
cancelled, replaced by the wire harness ASSY replacement.
