H
igh-Pressure-Cleaning-Systems
Ref. Description Part-No Quantity Ref. Description Part-No Quantity
1 Brass Manifold 44120341 1 110 Knob 36318751 1
2 Screw M8x60 UNI 5931 99319200 8 111 Ring nut 36318670 1
3 Washer 8 96701400 8 112 Nut M28x1,5 92293500 1
4 O-Ring 17,13x2,62 90384100 6 KIT123 113 Nut M8 UNI 5589 92221800 1
5 Valve seat 36200366 6 KIT123 114 Screw M8x20 UNI 5923 99305400 1
6 Valve 36200176 6 KIT123 115 O-Ring 20,35x1,78 90359800 1
7 Spring 9,4x14,8 94737600 6 KIT123 116 Pressure unit 36318570 1
8 Valve guide 36202551 6 KIT123 117 Spring plate 36316970 1
9 O-Ring 20,24x2,62 90384700 6 KIT124 118 Spring 94743600 1
10 Cap M24x1,5x17 98222600 6 KIT124 119 Spring 94734500 1
11 Valve unit 36711501 6 KIT123 120 Lower spring plate 36323370 1
12 Screw M6x10 UNI 5739 99180700 8 121 Bushing guide 36322870 1
13 Crankcase cover 50150074 2 122 O-Ring 23,81x2,62 90385700 1
14 Spacer 44211801 1 123 Security ring 90505200 1 KIT 137
15 O-Ring 55,56x3,53 90409700 1 124 O-Ring 9,13x2,62 90382000 1 KIT 137
16 Roller bearing 6305 91832800 2 125 Control piston 36323470 1 KIT 137
17 Oil seal 18x26x6 90159500 3 Kit 159 126 O-Ring 6,75x1,78 90357500 2 KIT 137
18 Crankcase 63010022 1 127 Security ring 90502500 1 KIT 137
19 Oil dipstick G 3/8 98210300 1 128 Spacer 36323070 1 KIT 137
22 Piston guide 63050066 3 129 Spring 18,5x11 94748500 1 KIT 137
23 Connecting rod 63030022 3 130 Valve 36323151 1 KIT 137
24 O-Ring 101,27x2,62 90392000 1 131 Valve guide 36322970 1 KIT 137
25 Crankcase cover 63160022 1 132 O-Ring 21,95x1,78 90360000 1 KIT 137
26 Screw M6x14 UNI 5931 99183700 5 133 Security ring 90514400 1 KIT 137
27 O-Ring 10,82x1,78 90358500 1 134 Valve 36319066 1 KIT 137
28 Cap G 1/4x9 98204100 1 135 Screw M5x7,5 99150900 1 KIT 137
29 Piston pin 9x27,5 97733500 3 136 Valve seat 36316466 1 KIT 137
30 Washer 9x25x0,5 96707500 3 137 O-Ring 9,92x2,62 90382200 1 KIT 137
31 Security ring 90502200 3 138 Anti-extrusion ring 90506500 1 KIT 137
32 O-Ring 5,28x1,78 90357300 3 139 O-Ring 13,95x2,62 90383200 1 KIT 94
33 Piston 18 44040109 3 140 Nipple M22x1,5 10014770 1
34 Washer 8 44211570 3 141 Cap M14x1,5 98205700 1
35 Nut M8 92221600 3 142 Cap G1/4x9 98204100 1
37 Foot 50200074 2 143 Manifold 63120441 1
38 Washer 8 UNI 1751 96701600 4 150 O-Ring 9,92x2,62 90382200 1 KIT 94
39 Screw M8x16 UNI 5739 99303700 4 151 Nozzle 2,0 10015166 1
40 Packing retainer 18 63080170 3 152 O-Ring 9,25x1,78 90358200 1 KIT 94
41 O-Ring 28,3x1,78 90360800 3 153 Tapered spring, 4,3/7,3x11 94821700 1 KIT 94
42 Packing 18 90265000 3 KIT 161 154 Ball 7/32“ 97478200 1 KIT 94
43 Intermediate ring 18 63216170 3 KIT 161 155 O-Ring 5,28x1,78 90357200 1 KIT 94
44 Packing 18 90265400 3 KIT 161 156 Spring 9,75x10 94738300 1 KIT 94
45 Cap G 3/8x13 98210000 1 157 O-Ring 8,73x1,78 90358000 1 KIT 94
46 Cap G 1/2x10 98217600 1 158 Shutter 36256470 1
47 Washer17,5x23x1,5 96738000 1 159 Knob 36256551 1
48 Washer 21,5x27x1,5 96751400 1 160 O-Ring 4,48x1,78 90357000 2 KIT 94
49 Oil level indicator 63210051 1 161 Coupling hose fitting 36256670 1
50 O-Ring 26,58x3,53 90405100 1 162 Metering body 36318151 1
68 Circlip 90063500 1 163 O-Ring 10,82x1,78 90358500 1 KIT 94
69 Crankshaft 63025265 1 164 Valve seat 36256370 1
70 Needle bearing 91856800 1 170 O-Ring 17,13x2,62 90384100 1
71 Screw M8x25 UNI 5739 99306700 4 171 Nipple water inlet G3/4 36318251 1
72 Flange 10049422 1 172 Filter 92892500 1
73 Oil seal 45x62x8 90169000 1 173 O-Ring 12,37x2,62 90382800 1
74 Washer 6, Schnorr 96693800 4 174 Hose fitting water inlet 36256951 1
75 Screw M6x30 UNI 5931 99191200 4 175 Ring nut 92982800 1
Recommanded spare part set
Spare part set valves KIT KIT 94 1 Spare part set sleeves KIT KIT 161 1
Spare part set valves KIT KIT 123 1 Spare part set KIT KIT 163 1
Spare part set KIT KIT 124 1 Spare part set KIT KIT 165 1
Spare part set valves KIT 137 1 Spare part set KIT KIT 167 1
Spare part set seals KIT KIT 159 1
Spare part list
Motor KD 623 5770 1 Cover 58600000000000 1
Motor KD 723 3486 1 HP-Hose 10 m 574601 1
Motor KD 740 3487 1 HP-Trigger-gun 58720000000000 1
Main switch KD 623 58810000000000 1 Hi-Lo-Nozzle KD 623 / 723 58740000000000 1
Main switch KD 723 58820000000000 1 Hi-Lo-Nozzle KD 740 58730000000000 1
Main switch KD 740 2949 1 Turbo-Nozzle KD 623 / 723 58790000000000 1
Pressure gauge 58710000000000 1 Turbo-Nozzle KD 740 58750000000000 1
Wheel 5869 2
