29 www.ehs-heating.com
10.6.2. Press “UP / DOWN” to adjust hour,
10.6.3. then press “MODE” key again to get minutes to flash
10.6.4. Press “
UP / DOWN” adjustment for minutes.
10.6.5. Press
“CONFIRM” to complete the setting.
10.7. Week Settings:
10.7.1. In Standby/Summer mode status, press “MODE” 5 times and is flashing.
10.7.2.
Press “UP / DOWN” to set the day of the week.
10.7.3. Press
“CONFIRM” to complete the setting.
10.8. Boiler 24 Period timing and each timing temperature set:
10.8.1. Press “Clock” key to enter the on / off time setting, the 24-hour time period flashes.
10.8.2. Press
“UP / DOWN” to make the on / off hour setting. (Note: Press “UP” Select this segment time
on-the segment lamp is on , Press “DOWN” Cancel the segment timing-segment light off .
And
then press “MODE” and the flashes. Press
“UP / DOWN” to set the temperature. Long press
“Clock” for 3 seconds until the icon is light and timing function starts.
10.8.3. (1-24) Time on / off / temperature setting is completed. After the appointment time / temperature
setting, press the “TIME” for 3 seconds to enter the reservation time / temperature on / off.If there is
no need to set the timing function, press the 3-second “TIME” key to exit the reservation function.
Note: (The second grid from left to right is the first hour. ）
10.9. Heating temperature setting:
10.9.1. In radiator mode , the heating water temperature can be set 30℃-80℃.
10.9.2. In floor heating mode , the heating water temperature can be set 30℃-60℃
10.10. Direct Hot Water temperature setting range: Hot water temperature can be set up the temperature
range: 30℃ -60℃.
11. Electrical Circuit Diagrams and Technical Data
Circuit Diagram
