We do not recommend wall mounting of Smoke Alarms.
On a Sloping Ceiling
With a sloping or peaked ceiling install a Smoke Alarm within 600mm of the peak
(measured vertically). If this height is less than 600mm it is regarded as being flat
(see Figure 4).
10
DEAD AIR SURFACES
NEVER WITHIN 300mm
OF ANY CORNER
IDEAL IN CENTRE
OF CEILING
SMOKE ALARMS
<600mm
APEX
xx
Figure 3
Figure 4
