User Manual EickSonic II – ENGL
19/28
2 Product Function and Operation
2.1 Operation
1.
Open the packing box, make sure that all the parts and accessories are complete according to the
packing list.
2.
Take the main unit out of the box and put it on a stable plane.
3.
Turn the water control knob in clockwise direction to the maximum and turn the vibrating intensity
control knob towards clockwise direction to a suitable position.
4.
Insert the plug of the foot switch to its socket.
5.
Connect one end of the water pipe to the water entrance, and the other end to the pure water
source.
6.
Connect the handpiece: screw on the scaling tip to the handpiece by the torque wrench, then insert
the connector of the cable to the handpiece correctly.
7.
Get through to the power.
8.
Press the power switch of the main unit, then the power indicator shines.
2.2 Operation Method and Function Instruction
1.
Make the scaler straight to the operator. Before turning on, please turn the vibrating intensity
control knob to the minimum and water control switch to the maximum (turn three circles towards
clockwise direction from the minimum to the maximum).
2.
The normal frequency is as high as 28 kHz +3 kHz. Under normal working condition light touch and
a certain to-and-fro motion will eliminate the tartar without obvious heating. Overexertion and
overstay are forbidden.
3.
Select a suitable scaling tip according to your request, screw it on to the handpiece tightly by the
torque wrench (as showed in the picture 4).
4.
Step on the foot switch, the tip begins to vibrate, and the LED lamp on the top of the handpiece
shines. Release the foot switch, the LED lamp keep shining for 10 seconds.
5.
Vibrating intensity: Adjust the vibrating intensity as you need, generally turn the knob to the middle
grade. Because different patients have different sensitivity and the rigidity of the gingival tartar is
not alike too, the vibrating intensity should be adjusted during the clinical treatment.
6.
Water adjustment: Step on the foot switch, the tip begins to vibrate, then turn the water control
switch to form fine spray to cool down the handpiece and clean the teeth.
7.
The scaler tip has to vibrate before it can be used on a tooth.
8.
The handpiece can be handled in the same gesture as a pen in hand.
9.
Make the tip touch the surface of the teeth lightly, do not use too much pressure, or else the teeth
will be hurt and the scaling tip will be damaged.
10.
After finishing operation, keep the machine working for 30 seconds with the water supply, so that
the handpiece and the scaling tips can be cleaned.
11.
Pull out the handpiece and unscrew the scaling tip, make them be sterilized.
NOTICE
Do not pull out the handpiece when the foot switch is stepped on and the machine is working.
