Eighteeth NanoPix1 - Technical Data

10 Technical Data
Page 58 / 66
10. Technical Data
Manufacturer
Changzhou Sifary Medical Technology Co., Ltd
Model
□NanoPix1 / □NanoPix2
Dimensions
19.6cm x 14.4cm x 3.4cm±1cm(Package)
Weight
0.4kg ± 10%
Effective imaging area
NanoPix1: 20x30mm
2
NanoPix2: 26x36mm
2
Power
1.5W Max
Sensor technology
CMOS CsI
Pixel size
20um
Theoretical resolution
20 pl/mm
X-ray energy range
55~100kV
Data interface
USB2.0
Electrical safety class
Depend on the computer terminal that the sensor
is connected to.
Protection against liquid / particular
matter
IP68 (Intraoral part of sensor)
IPX8 (USB cables)
Anti-defibrillation application part
No
AP/APG type equipment
Non-AP/APG type equipment
Operating conditions
Use: in enclosed spaces
Ambient temperature: 10°C ~ 35 °C
Relative humidity: 20% ~ 90%
Operating altitude < 3000m above sea level
Transport and storage conditions
Ambient temperature: -20 °C ~ 55 °C
Relative humidity: 20% ~ 80%, no condensation
Atmospheric pressure: 70kPa~106kPa
