Empty the tank as described below:
1. Pull out the mains plug.
2. Slide tank under the drainage screw.
3. Unscrew the drainage screw (1).
4. Remove the bung (2).
5. The condensation water drains out into the tankl.
6. Once the condensation water has been completely
emptied, fit the bung (2) and the drainage screw
(1) back on again.
7. The device is then ready to be used again.
D) Draining off the condensation water
with the condensation water hose
1. Pull out the mains plug.
2. Unscrew the drainage screw (1).
3. Remove the bung (2).
4. Fit the condensation water hose and secure with
the clamp.
5. The drainage hose can be extended with a hose
with a diameter of 18mm. If you do so, make sure
you use a suitable connector.
Note:
The drainage hose must run to the outside with a
slight fall.
15
GB
1
2
Condensation
water hose
Condensation
water hose
Reduced water hose with
a diameter of 18 mm
2
1
