4. Technical data
Motor power supply: ............................18 V
No load speed: ........................... 1100 rpm (min
-1
)
Blade length: ................................20.5 in. (52 cm)
Cutting length: ..............................18.1 in. (46 cm)
Cutting diameter max.: ................0.43 in. (11 mm)
Weight: .............................................4.4 lbs (2 kg)
Wear ear-muff s.
The impact of noise can cause damage to
hearing.
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect
condition.
•
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
5. Before starting the equipment
5.1. Installing the battery (Fig. 3)
Press the pushlock button of the battery pack
as shown in Fig. 3/Item 8 and push the battery
pack into the mount provided. When the battery
is positioned as in Fig. 1, make sure that the
pushlock button (8) latches in place! To remove
the battery pack, proceed in reverse order.
6. Operation
Switching ON/OFF.
The hedge trimmer is equipped with a two-
handed safety switch. It works only when the
switch on the steady grip (Fig. 1/Item 3) is
pressed with one hand and the switch on the
handle (Fig. 1/Item 4) is pressed with the other
hand. If either switch is released, the cutters will
stop moving. Please watch out for the cutters as
they slow down to a standstill.
Work practice
•
A hedge trimmer can be used to cut shrubs
and bushes as well as hedges.
•
To obtain the best cutting results, hold the
hedge trimmer so that the cutter teeth are
at an angle of approx. 15° in relation to the
hedge (see Figure 5).
•
The twin-bladed cutters rotate in opposite
directions, thus enabling cutting in both
directions (see Figure 6).
•
It is recommended to tie a guide line of string
or the like along the hedge so that you cut the
hedge to a level height. Cut off all branches
which protrude beyond the guide line (see
Figure 7).
•
Cut the sides of the hedge with curve-shaped
movements from the bottom up (see Figure
8).
6.1 Charging the Li battery pack
The corresponding instructions can be found
in the original operating instructions for your
charger.
6.2 Battery capacity indicator (Fig. 4 / item 9)
Press the battery capacity indicator switch (10).
The battery capacity indicator (9) shows the
charge status of the battery using 3 LEDs.
All 3 LEDs lit:
The battery is fully charged.
2 or 1 LED(s) lit:
The battery has an adequate remaining charge.
1 LED fl ashing:
The battery is empty, recharge the battery.
All LEDs fl ashing:
The battery pack has been deep-discharged and
is defective. Do not re-use or charge a defective
battery pack.
