EINHELL AXXIO 36/230 Q User Manual

GB
- 17 -
Tool side Suitable for
Left (position A / as
shown)
Right-handed users
Right (position B) Left-handed users
Top (position C) Using cutting wheels
5.2 Replacing and adjusting the guard
(Fig. 3)
Replacing:
•
Remove the quick-clamp nut (5) and the
clamping flange underneath.
•
Open the clamp lever (a) on the guard (4).
•
Turn the guard (4) through 180° in clockwise
direction so that the guard points upwards.
•
Remove the guard (4).
To mount, proceed in the reverse order.
Adjusting:
•
Adjust the guard (4) to protect your hands
so that the material being ground is directed
away from your body.
•
The position of the guard (4) can be adjusted
to any specific working conditions. Undo the
clamp handle (a) and turn the cover (4) into
the required position.
•
Ensure that the guard (4) correctly covers the
gear wheel casing.
•
Secure the clamp handle (a) again.
•
Ensure that the guard (4) is secure.
Warning!
Make sure that the guard is perfectly secure.
Warning!
Never use the angle grinder without the gu-
ard.
5.3 Swivel handle (Fig. 4)
The handle can be swiveled a maximum 90° to
the left and right. To do so, press the locking plate
(7) and swivel the handle 90° to the left or right.
Important. When the locking plate (7) engages
correctly it makes an audible click.
6. Operation
6.1 Charging the Li battery pack (Fig. 5-6)
1. Remove the battery pack (b) from the handle,
pressing the pushlock button (c) downwards
to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(d) into the mains socket outlet. The green
LED will then begin to fl ash.
3. Push the battery pack onto the battery char-
ger.
In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit
If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you
notice that the performance of the device drops.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
6.2 Switch (Fig. 7)
The angle grinder comes with a safety switch
which is designed to prevent accidents. To start
the equipment push the locking lever (a) forwards,
then press the ON/OFF switch (3).
Anl_AXXIO_36_230_Q_SPK13.indb 17Anl_AXXIO_36_230_Q_SPK13.indb 17 01.12.2021 13:11:2101.12.2021 13:11:21

EINHELL AXXIO 36/230 Q Specifications

General

Motor type	Brushless motor
Product color	Black, Red
Adjustable speed	No
Restart protection	Yes
Number of handle positions	3
Idle speed (max)	6600 RPM
Idle speed (min)	0 RPM
Cutting depth (max)	70 mm
Grinding disc diameter	230 mm
Power source	Battery
Battery voltage	36 V
Battery capacity	3 Ah

Weight and Dimensions

Weight	4210 g
Package depth	280 mm
Package width	545 mm
Package height	190 mm
Package weight	6600 g
