9
GB
1
2
3
4
5
Changing the saw
blade
Releasing the saw blade:
Turn screw anticlockwise.
Locking button
On/Off switch
Insert the saw blade in the
ram up to the stop and
tight the screw of the
retention clip.
Important: Make sure that
the saw blade sits pro-
perly in the slot of the rol-
ler and ram.
Switching on: Press the On/Off switch
Continuous operation: Lock the On/Off switch with the
locking button
Switching off: Press the On/Off switch
and release
Turn the speed controller to increase the
cutting rate
Undo the two screws to set the base to an angle of up to
45° on the right or left side.
Cutting holes: Possible only in chipboard and wood unless
you drill a hole first. Press the jigsaw firmly against the
support and move slowly in cutting direction.
Cutting veneered chipboard:
1. Use a fine saw blade
2. Position the base on the uncovered area
3. Advance the saw with little force
Support
45°
30°
45°
15°
0°
30°
15°
0°
