9
GB
1
2
3 4
5
6
On/Off switch
Locking button
Turn the speed controller to increase the
cutting rate
The soleplate can be adjusted through 45° by loosening
the screw.
Setting the pendulum action
Position 0: No pendulum aktion
Position 1: Slight pendulum action
Position 2: Intensive pendulum action
Operating the laser
You can switch the laser ON and OFF with the switch 1.
The laser beam marks the line of the cut on the work-
piece.
Switching on: Press the On/Off switch
Continuous operation: Lock the On/Off switch with the
locking button
Switching off: Press the On/Off switch
and release
