8
GB
TECHNICAL DATA
Nominal voltage: 230 V ~ 50 Hz
Power consumption: 750 W
Cutting rate: 600-3000 strokes/min.
Stroke height: 18 mm
Cutting depth in wood: 100 mm
Cutting depth in plastic: 20 mm
Cutting depth in iron: 10 mm
Mitre cuts: up to 45° (left and right)
Sound pressure level LPA: 85,3 dB(A)
Sound power level LWA: 96,3 dB(A)
Vibration a
w
≥ 2,5 m/s
2
Double isolation II /
Weight 2,3 Kg
Laser class 2
Laser wave length 650 nm
Laser output ≤ 1 mW
Laser module power supply 2 x 1,5 V (AAA)
Ordering replacement parts
Please quote the following data when ordering repla-
cement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
Replacement part Replacement part number
Carbon brush 43.210.30.01.001
Switch 43.210.30.01.002
