Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
1 340035002001 UPPER HANDLE
3 340035002003 Handle Rotating button unit
4 340035002004 MIDDLE HANDLE
5 340035002005 CORD PLATE
12 340035002012 REAR COVER SHAFT PIN
20 340035002020 REAR WHEEL UNIT Ø 185mm
21 340035002021 SOFT SHAFT
30 340035002030 FRONT WHEEL UNIT Ø 160mm
34 340035002034 BLADE PLATE UNIT
36 340035002036 blade fixing screw
38 340035002038 SPANNER
