6. Operation
•
Install the equipment on a solid and level
surface.
•
Fill the pump housing with water via the water
filler screw (5). Filling the intake line will acce-
lerate the priming process.
•
All the shut-off devices in the discharge line
(spray nozzle, valves etc.) must be fully ope-
ned during intake in order to permit all air to
escape from the intake line.
•
Connect the mains cable.
•
Switch on the equipment with the power
switch (7) - water can be suctioned in for up
to 5 minutes (maximum suction height).
•
The equipment will shut down when the cut-
out pressure of 3 bar is reached.
•
After a loss of pressure due to water con-
sumption the equipment will cut in again auto-
matically (cut-in pressure approx. 1.5 bar).
•
After finishing the work, switch off the equip-
ment with the power switch (7).
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
The equipment is almost completely maintenance
free. In order to ensure a long service life, howe-
ver, we recommend that you regularly check and
care for the product.
Danger!
The equipment must be disconnected from the
power supply (pull the power plug) prior to perfor-
ming any maintenance.
8.1 Servicing
•
If the equipment becomes clogged, connect
the discharge line to the water line and dis-
connect the suction hose. Open the water
line. Switch on the equipment several times
for approx. two seconds. This should resolve
the majority of clog-related problems.
•
Inside the pressure tank is an expandable
water sack and an air compartment whose
maximum pressure should lie at approx. 1.5
bar. Pumping water into the water sack cau-
ses the sack to expand so that the pressure in
the air compartment rises to switch-off level. If
the air pressure is too low, you should raise it.
To do so, unscrew the plastic lid from the tank
and top up the pressure to the correct level
using a tyre pump with meter at the valve.
Important: Be sure to completely empty
the water bag first using the water drain
screw (2).
•
Replacing the mains cable: Important:
Disconnect the equipment from the power
supply! A defective mains cable may only be
replaced by a qualified electrician.
•
There are no parts inside the equipment
which require additional maintenance.
8.2 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
•
Type of machine
•
Article number of the machine
•
Identification number of the machine
•
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
Anl_GC_WW_1046_N_GC_WW_1250_NN_SPK9.indb 18 31.01.2019 07:16:22

EINHELL GC-WW 1250 NN Specifications

General

Flow rate	5000 l/h
Maximum suction height	8 m
Maximum delivery height	50 m
Maximum operating pressure	5 bar
Maximum input water temperature	35 °C
Proper use	Garden
Product color	Red, Stainless steel
Drive shaft material	Stainless steel
AC input voltage	220-240 V
Power cable type	H07RN-F
Power source type	AC
AC input frequency	50 Hz
Cable length	1.5 m
Suction port	1 1/4\
Discharge port	1\
Package depth	585 mm
Package height	542 mm
Package weight	17300 g

Weight and Dimensions

Weight	14700 g
Diameter	300 mm
