12
correct operation and safety regulations (see
supplementary sheet) before using for the first time.
4.2. Additional safety instructions
앬 Set up the machine on a level, non-slip floor.
Make sure that the machine does not wobble.
앬 Check that the voltage on the rating plate is the
same as your supply voltage. Only then are you
to insert the power plug in the socket-outlet.
앬 Wear safety goggles.
앬 Wear ear-muffs.
앬 Wear safety gloves.
앬 Never use cracked diamond cutting wheels.
Replace immediately.
앬 Never use segmented cutting wheels.
앬 Caution! The cutting wheel runs on after the
machine is switched off!
앬 Never apply side pressure to the diamond cutting
wheel in order to bring it to a halt.
앬 Caution! The diamond cutting wheel must be
cooled with water at all times.
앬 Always pull out the power plug before changing
the cutting wheel.
앬 Use only suitable diamond cutting wheels.
앬 Never leave the machine unattended in rooms
with children.
앬 Always pull out the power plug before examining
the electric motor compartment system
.
5. Technical data
Motor rating 1500 W S2 20 min
Motor speed 3000 rpm
AC motor 230 V ~ 50 Hz
Insulation material class Class B
Protection type IP54
Table size 630 x 450 mm
Cut length
570 mm
Jolly length
570 mm
Max. workpiece thickness 90° 65 mm
Max. workpiece thickness 45° 48 mm
Diamond wheel Ø 250 x Ø 25.4
Weight 54 kg
Laser class 2
Laser wavelength 650 nm
Laser output < 1 mW
Laser power supply 2 x 1.5 V (AAA)
앬 Load factor:
A load factor of S2 20 min (intermittent periodic
duty) means that you may operate the motor
continuously at its nominal power level (1500 W)
for no longer than the time stipulated on the
specifications label (20 minutes ON period).
If you fail to observe this time limit the motor will
overheat. During the OFF period the motor will
cool again to its starting temperature.
Noise emission levels
앬 The noise emitted by this saw is measured in
accordance with EN ISO 3744; EN ISO 11201
The noise at the workplace may exceed 85 db
(A). The user will require noise protection
measures if this is the case. (Wear ear-muffs!)
No-Load operation
Sound pressure level 94,5 dB(A)
Sound power level 107,5 dB(A)
6. Before using for the first time
앬 The machine must be set up so that it stands
firmly, i.e. it must be securely screwed to a work
bench, the base frame supplied in delivery, or
similar.
앬 All covers and safety devices must be correctly
attached before the machine is used for the first
time.
앬 The cutting wheel must rotate smoothly.
앬 Check that the voltage on the rating plate is the
same as your supply voltage before you connect
the machine to the power supply.
7. RCD plug (Fig. 16)
Connect the RCD plug (41) to the power supply.
Press the reset button (42) and the control lamp (43)
will begin to shine. Press the test button (44) to
check the function of the RCD plug. If everything is
working properly the control lamp (43) will go out and
the contact to the power supply will be interrupted.
The RCD plug triggers at a fault current of 30 mA.
Defective RCD plugs must be replaced by a qualified
electrician.
Press the reset key (42) again in order to be able to
start up the machine.
GB
