6.3 Setting the unit of measurement
(Fig. 3 Item 4 F)
The default unit of measurement is the metric
meter (m). But you can also select from three
other unit settings. To do so, press the F button
and keep it pressed until the unit changes. Keep
repeating until the unit you require is displayed.
6.4 Setting the reference point (Fig. 3 - 4)
Measurements can be performed from three diff e-
rent reference points on the equipment. To do so,
press the F button briefl y and select the reference
point you require.
•
Front edge reference point (see Fig. 4a)
•
Rear edge reference point (see Fig. 4a)
•
Swing-out stop reference point (see Fig. 4b)
6.5 Using the measurement functions
Note:
The laser beam switches off automatically after
completion of each measurement. Press the ON/
Measuring button.
6.5.1 Function: “Measure single distance”
“No symbol” (Fig. 5)
Procedure:
•
Press button A once and keep it pressed for a
short time: Switch on the equipment
•
Button F if necessary: Select the reference
point on the equipment
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure
→ The result is displayed at the bottom in m
6.5.2 Function: “Measure continuous
distance (min/max)”
“Symbol
” (Fig. 6)
Procedure:
•
Press button A once and keep it pressed for a
short time: Switch on the equipment
•
Button F if necessary: Select the reference
point on the equipment
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A for 2 seconds: Continuous
measurement
→ Min: The lowest measurement result is dis-
played (Fig. 6a)
→ Max: The highest measurement result is
displayed (Fig. 6b)
The current measurement result is displayed
right at the bottom in real time
6.5.3 Function: “Measure areas”
“Symbol
” (Fig. 7)
Procedure:
•
Press button A once and keep it pressed for a
short time: Switch on the equipment
•
Press button B once: Select function
•
Button F if necessary: Select the reference
point on the equipment
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the area length
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the area width
→ The result is displayed at the bottom in m²
6.5.4 Function: “Measure volumes”
“Symbol
“ (Fig. 8)
Procedure:
•
Press button A once and keep it pressed for a
short time: Switch on the equipment
•
Press button B twice: Select function
•
Button F if necessary: Select the reference
point on the equipment
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room
length
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room width
•
Press button A once: Switch on the laser
•
Align the laser
•
Press button A once: Measure the room
height
→ The result is displayed at the bottom in m³
6.5.5 Function: “Measure two adjacent areas”
“Symbol
“ (Fig. 9)
Procedure:
•
Press button A once and keep it pressed for a
short time: Switch on the equipment
•
Press button B three times: Select function
•
Button F if necessary: Select the reference
point on the equipment
