EINHELL TC-LD 50 Operating Instructions

GB
- 19 -
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Laser distance meter
•
Bag
•
Original operating instructions
3. Proper use
The laser is designed for measuring distances,
areas and volumes.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Range: ................................................0.05 - 50 m
Accuracy: ............................................... +/- 2 mm
Power supply: .............. 2 x 1.5V; type AAA (LR03)
Laser class: ........................................................ 2
Wavelength of laser: ................................ 635 nm
Laser output: ............................................ < 1 mW
5. Before using the equipment
Inserting/changing batteries (Fig. 2)
•
Switch off the equipment.
•
Remove the battery compartment cover (6)
by pressing in the fastener (a) and flipping up
the battery compartment cover.
•
Insert the batteries (b), ensuring that you fit
them the right way round.
•
Fit the battery compartment cover back on,
making sure that the fastener snaps into
place.
6. Operation
Important!
The measuring distance and measuring accuracy
can be aff ected by ambient conditions such as
sunlight or poor refl ection and this can have an
adverse eff ect on the measurement result.
6.1 Description of the function buttons
(Fig. 3)
A ON/Measuring button
B Measurement options button
C OFF/Delete button
D Addition
E Subtraction
F Selection of the reference point for distance
measurement / Selection of the measuring
unit
6.2 Switching the laser on/off
•
To switch the laser on, press the ON/Measu-
ring button (A) and keep it pressed for a short
time.
•
To switch off the laser, press the OFF button
(C) and keep it pressed for about 1 second.
Anl_TC_LD_50_SPK9.indb 19Anl_TC_LD_50_SPK9.indb 19 22.04.2021 09:47:3222.04.2021 09:47:32

EINHELL TC-LD 50 Specifications

General

Type	Laser distance meter
Display type	Digital
Product color	Black, Red
Distance measuring units	m
Wavelength	635 nm
Laser class	2
Maximum measurement distance	50 m
Minimum measurement distance	0.05 m
Battery type	AAA
Auto power off	Yes
Battery voltage	1.5 V
Auto power off after	3 min

Weight and Dimensions

Weight	120 g
Package depth	67.8 mm
Package width	113 mm
Package height	200 mm
Package weight	310 g
