1 APPLICATION AREA
The electronic timer TE-80 from EKF PROxima is designed for
automatic switching on/off of household and industrial appliances
and electrical installations according to the installed weekly
program. The product corresponds to IEC 60730-2-7.
2 TECHNICAL DATA
The main technical data of electronic timer are given in table 1.
Table 1
Parameter
Value
TE-80
TE-80
24-230 V
TE-80-2 24-
230 V
Rated power supply voltage
(Un), V
AC 230 AC/DC 24-264
Rated frequency, Hz 50/60
Maximum switching current
of contacts (AC-1), А
16
Type and number of contacts 1 CO 2 CO
Insulation voltage, Ui, V 300
Power consumption, W 1 2
Program type Weekly, impulse
Operating mode Hand, automatic
Switching to winter/summer time OFF/automatic
Memory capacity Up to 80 programs
Accuracy of clock rate per day
at 20°С, s
1
Electrical durability, cycles 100 000
Mechanical durability, cycles 1 000 000
