EKF TE-80 - Settings and Programming

6
The terminal screws of the relay allow to connect copper or
aluminum conductors with cross section of no more than 4 mm
2
.
Before connection of stranded conductors, they should be
terminated with a tip or sleeve using an appropriate tool. The
mounted-in battery will be fully charged during 24 hours from the
moment of timer activation.
3. 1 SETTINGS AND PROGRAMMING
Primary settings
1
1 2 3
2
5 6
3
4
4
5
6
7
OK
OK
OK OK OK
MENU
When you turn on the timer for the rst time (or after reset
settings), you can set date, time, language by using buttons «up/
down» and «OK» .
In order to enter the menu, press and hold the «MENU» button
for 2 seconds.
