1 DESCRIPTION
Frequency converter VECTOR-100 EKF is designed to control the rotation
speed of industrial electric motors. Frequency converter enables
accurate control of the motor rotation speed based on external input.
Frequency converter complies with IEC 61800-5-1, IEC 61800-3
requirements.
Type code:
VT100-XX -X X
Frequency converters VECTOR series
VT100 – industrial frequency converter
VECTOR-100 EKF.
Rated (extended) motor power: 0R4 – 0,4 ( 0,75) kW;
0R75 – 0,75 (1,5) kW; 1R5 – 1,5 (2,2) kW; 2R2 – 2,2 (4) kW,
4 – 4 (5,5) kW, 5R5 – 5,5 (7,5) kW; 7R5 – 7,5 (11) kW;
11 – 11 (15) kW … 560 – 560 (630) kW; 630 – 630 (750) kW.
Input phases:
1 – single-phase 230V;
3 – three-phases 3x400V.
Braking unit:
B – integrated;
No marking – not included.
