2 TECHNICAL DATA
Main technical data are given in Table 1 below.
Characteristics Значения
Minimal single-phase power (1x230V), kW 0,4
Maximum single-phase power (1x230V), kW 2,2
Minimal three-phase power (3x400V), kW 0,75
Maximum three-phase power (3x400V), kW 630
Output frequency, Hz
0-600
Output voltage @ 3x400V input, V 400
Carrier frequency, kHz 0,4-16
Starting torque, %
SVC - 150
at 0,5 Hz
V/F – 150
at 1 Hz
Overload capacity, %
150 for 60 s
180 for 3 s
Non-feedback vector control (SVC) Available
Scalar control V/F Available
Inputs/Outputs
Digital input connections 5 to 7
Analog input connections 2 to 3
Digital output connections, relay/transistor
0,4 to 7,5 kW
> 11 kW
1/2
2/2
Analog output connections 2
Interfaces
RS-485, Modbus RTU protocol Available
Functions
PID Available
Sequential PLC Available
Design
Cooling Fan
 -10…+50
Degree of protection IP20
Table 1
