EKO CORE 500 Quick Start Guide

4
86
BPM
Understand CORE 500™ Screen
Resting state
1
2
3
8
6
5
4
1. Current audio filter:
• Wide (for all use cases)
• Cardiac (with ECG)
• Pulmonary (with lung sounds)
2. Top button:
a. Change filter:
= short press for <1 second
b. Start recording:
= long press for 2 seconds
3. Battery level
4. Bluetooth connected
5. Volume up button
6. Volume down button
7. Real-time heart rate in beats
per minute
8. Leads indicator:
a. O= No skin contact detected
b. ✓ = Skin contact detected
7

EKO CORE 500 Specifications

General

Type	Digital Stethoscope
Connectivity	Bluetooth
Amplification	Up to 40x
Active Noise Cancellation	Yes
FDA Clearance	Yes
HSA/FSA eligibility	Yes
Water Resistance	IPX4
Compatibility	iOS and Android
Frequency Response	20Hz - 2000Hz
