Ekopower EkoHeat Series User Manual

INSTALLATION AND OPERATING INSTRUCTIONS
 EKOHEAT

Ekopower EkoHeat Series Specifications

General

Brand	Ekopower
Model	EkoHeat Series
Category	Boiler
Language	English

Summary

List of Components

Control Components

Boiler Temperature Selector

Used to select the boiler set point temperature (65-80°C).

DHW Temperature Selector

Used to select the desired domestic hot water set point temperature (15-65°C).

Digital Display

Shows operating info, settings, and values; used for configuration access.

Start/Stop Touch Button

Touch button to start up or switch off boiler functioning.

Info Touch Button

Touch button to access boiler information.

Menu Touch Button

Touch button to access different boiler menus.

Safety Thermostat

Ensures boiler temperature does not exceed 110°C by cutting off electrical supply.

Installation Instructions

Location and Ventilation

Boiler must be installed in a ventilated site, away from humidity, with clear space.

Hydraulic Installation

Installation must be made by qualified personnel, complying with legislation.

Installing a Sanit Hot Water Tank

Procedure for connecting a Sanit DHW tank to the Ekoheat boiler.

Fuel Requirements

Boiler must be fuelled by EN PLUS certified wood pellet; store dry.

Installing the Reserve Tank

EKOPOWER supplies a reversible reserve tank for storing pellets.

Electrical Connection

Boiler has a 230V~ 50Hz mains plug; socket needs earth connection.

Combustion Product Removal

Boiler must be connected to a flue to create pressure drop; use fume inspection plate.

Example: Radiator Heating Installation

Boiler governs a radiator heating circuit with an external circulation kit.

Example: Zoned Heating Installation

Boiler can be fitted in installations with separate heating zones.

Example: MS Hydraulic Kit Installation

MS hydraulic kit for underfloor heating and DHW storage circuit control.

Example: Solar DHW Backup Installation

Boiler as back-up for solar installation for DHW production by storage.

External Circulation Kit

List of Components

List of components supplied in the external circulation kit box for installation.

Electrical Connection for Circulating Pump

Procedure for connecting the circulating pump to the boiler's connection strip J1.

Hydraulic Installation of External Circulation Kit

Instructions for mounting the external circulation kit on the right or left of the boiler.

Starting Up the Boiler

Prior Warnings

General warnings before starting up the boiler for the first time.

Filling the Installation

Procedure for filling the hydraulic installation with water to 1-1.5 bars.

Electrical Connection

Boiler is supplied with a mains connection plug.

Start-up Procedure

Conditions and sequence for starting up the boiler by authorised personnel.

Installation Delivery

Technical Assistance Service explains boiler functioning and controls to the user.

Digital Display and Controls

Display Settings Overview

Details settings shown on the initial display: boiler/DHW temp, flame level, fan, feed auger.

Display Touch Buttons

Identifies touch buttons for adjusting settings, starting/stopping, and accessing info/menu.

Boiler Operation

Selecting Boiler Setpoint Temperature

Procedure to select the desired boiler functioning temperature (65-80°C).

Selecting DHW Setpoint Temperature

Procedure to select DHW temperature (15-65°C) when DHW tank is installed.

Info Display

Configuration Menu

Cleaning Settings

Functioning options for burner and fan cleaning devices.

Time Programmer

Daily time programmer to control boiler on/off times; 5 periods can be enabled.

Feed Auger Calibration

Calibrates fuel feed auger for correct boiler functioning and optimum pellet amount.

Burner Lubrication

Positions burner for lubrication maintenance of the burner cleaning device.

Language Selection

Used to change the language displayed on the boiler.

Date and Time Adjustment

Used to change the date and time shown on the boiler.

Service Menu

Fuel Consumption Settings

Adjusts pellet consumption (kg/hr) at full power based on model and pellet calorific value.

Fuel for Ignition Settings

Specifies pellet amount (grams) required for correct burner ignition.

Burner Cleaning Device Timing

Adjusts time (seconds) for burner cleaning device to return to closed position.

Fan Functioning Settings

Adjusts fan speed percentages for correct combustion values at different power modulations.

Minimum Power Setting

Selects minimum boiler operating power as a percentage of nominal power.

Maximum Power Setting

Selects maximum boiler operating power as a percentage of nominal power.

DHW Circuit Settings

Settings for controlling the DHW circuit using a 3-way valve and DHW sensor.

Minimum Pump Temperature

Circulating pump stops if boiler temp drops below this value (default 30°C).

Manual Ash Cleaning Cycles

Manually enable ash cleaning device functioning cycles (1-5 cycles).

Model Selection

Selects boiler model for control; change only during repair.

Auto-Test Function

View inputs and enable systems for maintenance and error detection.

Reset Default Configuration

Resets the electronic control to its default settings.

New Software Update

Update electronic control software version using a USB storage device.

Cleaning the Ash Drawer

Safety Warnings for Ash Drawer

Precautions and advice for safe handling and removal of the ash drawer.

Safety Cut-Outs

Burner Cut-Out

Message 'E05: Burner error'. Caused by burner anomaly or excessive temperature.

No Flame Cut-Out

Message 'E06: Flame defect'. Caused by insufficient flame lux level.

Temperature Safety Cut-Out

Boiler switches off if water reaches 110°C; reset needed after cooling.

Shutting Down the Boiler

Boiler Maintenance

Boiler and Flue Maintenance Frequencies

Table detailing important aspects to check and their recommended frequency.

Cleaning the Burner

Recommended procedure for correctly cleaning the burner.

Lubricating the Burner Cleaning Device

Recommended procedure for correct lubrication of the burner cleaning device.

Draining Condensation Water

Condensation water draining from flue must be free of obstructions.

Boiler Water Characteristics

Use of treated water recommended for heating installations with high water hardness.

Cleaning the Vent

Recommended procedure for correctly cleaning the vents.

Technical Characteristics

Diagrams and Measurements

Electrical Diagram

Circulating Pump Flow Curves

Sensor Settings

Alarm Codes

Guarantee Conditions
