ekwb EK-Loop D5 User Manual

- 6 -
STEP 2
Place the provided D5 Pump O-Ring into the marked groove.
STEP 3
Place the D5 Pump and D5 Pump holder in place and secure it with
provided M4 x 20 DIN7984 Screws. Do not use excessive force!
Max Torque: 0.6Nm
A leakage test is mandatory after fixing the screws. EK
recommends using the EK-Loop Leak Tester for the test. More
information on leak testing can be found here:
https://www.ekwb.com/shop/ek-loop-leak-tester-flex
STEP 2
STEP 3
D5 PUMP
HOLDER
For this step, you will need:
For this step, you will need:
D5 Pump
D5 Pump O-ring
Allen Key 2.5mm
D5 Pump mount-
ing screws M4x20
DIN7984 (4 pcs)
D5 Pump holder
D5 PUMP
O-RING
D5
PUMP
M4 x 20 DIN7984
SCREW
