Page 3-7
L-3 ELAC Nautik
3.4 TECHNICAL DATA
Supply voltage, nominal : 95 - 240 V AC, 50 - 400 Hz
(min. 85 V AC, max. 264 V AC)
10 - 30 V DC (option, via power pack)
Power consumption : Approx. 25 W
Operating temperature range : -15°C - +55°C
Storage temperature : -20°C - +60°C
Housing : Cast aluminium
Protection code : IP 53
Transducer impedance : 50 - 150 Ohms
Pulse length : 0.3, 1, 3 ms, (automatically switches to suit
range selected)
Measurement ranges : 0 - 10, 20, 50, 200, 500, 2000 m (or the
equivalent in feet or fathoms)
Auto range : depending on the water depth range scale of
200m or 50 m will be selected automatically
Digital Depth Information : 150% of measurement range for 0 - 10m
0 - 50m
120% for other ranges
Resolution : 1% of range selected
Measuring accuracy : 2.5% of depth reading
Display : Liquid Crystal Display,
Display size : 192 mm x 144 mm
Pixels : 640 (hor.) x 480 (vert.)
Minimum sounding depth : 0.5 m or equivalent ( Transducer depended )
Depth corrections Transducer-surface : up to 9.9 m
Starting with software version 1.82 : up to 29,9 m
Transducer-keel : up to 4.9 m
Standard frequencies (kHz) : 28, 30, 33, 38, 50, 100, 200, 210 (selectable)
2 Channel version : any combination of the frequencies above
Output power : 1000 W Max. dependent upon range selected
and transducer installed
Compass Safety Distance : Magnetic compass : 0.5 m
: Steering compass : 0.3 m
Dimensions : Height = 288 mm
Width = 336 mm
Depth = 156 mm
Weight : Approx. 8 kg
