Specifications
ELAN
gMV88 INSTALLATION MANUAL
© ELAN 2015 All rights reserved. Page 1
INPUTS & OUTPUTS
Source Inputs
HDMI 8 w/ audio breakout
HDBaseT ARP 8 incl. with HDBaseT
Analog Audio 16 pr RCA connector
Digital Audio
16 ea Optical SPDIF
16 ea RCA Coaxial SPDIF
Zone Outputs
HDBaseT 8 RJ45 Cat5e/Cat6/Cat7
HDMI
(mirrored to HDBaseT)
8 19pin standard HDMI
Analog Audio 16 pr RCA connector
Digital 16 ea RCA Coaxial SPDIF
AUDIO
Analog Inputs
Input Sensitivity 0-2Vrms
Lip Sync 0-170ms in 1ms increment
Analog Outputs
Volume Adjustment Range -99.5dB to 0dB
Format Conversion 2ch PCM to analog
Lip Sync 0-170ms in 1ms increment
Tone/EQ Range -20dB to +20dB in .5dB increment
Digital Inputs - Optical & Coaxial
Format Dolby 5.1, DTS, PCM Stereo
Format Conversion 2ch PCM to Analog stereo D/A
Lip Sync 0-170ms
Digital Outputs -Coaxial & HDMI
Format PCM (7.1ch) SPDIF from digital inputs
Format Conversion
2ch SPDIF from analog sources (requires
mirror of
analog zone output)
Lip Sync
0-170ms (requires mirror of analog zone
output)
Tone/EQ
Bass/Treble/5 band (requires mirror
of analog zone output)
HDMI Pass Through
Format – All audio formats including:
PCM (7.1ch) SPDIF, Dolby
©
Digital
& True HD, DTS-HD
©
& Master Audio
VIDEO
HDMI Inputs/Outputs
• HDMI 1.4a compliant
• 3D capable
• 36 bit deep color
• HDCP 1.1 compliant
• 6.75 Gps data rate
• 1080p, 1920x1080@60Hz,
HDTV compatible 340MHz up
to 16 bit Y-U-V 444 supported
@ 1080p/60)
HDBaseT Outputs
• HDMI compliant to v1.4a
• 3D capable
• Refresh rates 24Hz, 30Hz, 60Hz
• Uncompressed video resolution
1080p, 1920x1200
• Deep Color 24-48 bit
• Vertical Frequency
Range 50 – 60 Hz
• Digital Audio PCM/7.1ch formats
including Dolby Digital,
• True HD, DTS-HD & Master Audio
Zone Outputs Bi-directional serial and IR, Ethernet
Chassis Control Ethernet, Serial RS-232
GENERAL
Dimensions w/feet
(7U without feet)
17" x 12-1/4” x 14”"
431.80 x 311.15 x 355.60 mm
Included in box
(1) installation manual
Certifications CE, UL, IC, FCC
POWER
Mains supply
120/240 V~, 50Hz/60Hz, 3A max
Power Consumption
Mains off: < 0.01W
Networked standby, RS-232 only connected: < 0.5W
Networked standby, TCP/IP only connected: < 1.0W
Networked standby, RS-232 & TCP/IP connected: < 1.0W
Automatic networked standby mode is activated
10 minutes after loss of control signal via
Ethernet control port or RS-232 control port.
Specifications and descriptions subject to change due
to product upgrades and improvements.
