ELAN HOME SYSTEMS TS10 INSTALLATION MANUAL
© ELAN Home Systems 2010 | All rights reserved.
Page 10
Installation
The TS10 is designed to mount into a TS10BKT rough in bracket. The TS10BB back box
can be used in conjunction with the TS10BKT in installations where a back box is desired.
It can also be retrofitted into existing construction. See the TS10BKT and TS10BB
documentation for additional information.
When installing the TS10 in a retrofit application, the cutout dimensions are:
10.75” W X 6.15” H.
273.05 mm W X 156.21 mm H
Pre-Wire
TS10 Touchscreens require power and Ethernet connections to function correctly. Video
connections may also be required.
Control: Cat-5
Power: 2 Conductor (16 AWG)
Video: RG-6 or RG-59 Coaxial Cable
Control / Power
Run Cat-5 and 2 conductor wiring from the main equipment location (head-end) to the
location where the touchscreen will be installed. Make sure that provisions have been made
for installation of a PPSP Power Precision Panel (typically at the headend).
Alternatively, the TS10 can be powered using a PoE adapter. Refer to the PoE Integration
Note for additional details.
Video
TS10 Touchscreens have both a Video Input and a Video Loop Output for composite video
signals. Run RG-6 or RG-59 coaxial cable from the headend location (possibly a video
switcher) to the location where the touch panel will be installed. Be careful not to make
sharp bends when installing coax. F-to-RCA connectors will be necessary to adapt the RCA
composite output of the video source (or switcher) to the F-connector of the coax run. The
TS10s have female F-connectors for both Video Input and Loop Output.
When using the Loop Output to send video signals to another display be sure to set the 75
Ohm termination switch to OPEN.
Note: Maximum wire run is 330 feet (100 meters).
