DMX Channel Values / Functions (37 DMX Channels)
Supports Software Versions: ≥ 1.3.0
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
10 12 18
STATIC-STAMPED GOBOS [GOBO WHEEL 2]
0-9
OPEN
10-17 Static-Stamped Gobo 1
18-25
Static-Stamped Gobo 2
26-33 Static-Stamped Gobo 3
34-41
Static-Stamped Gobo 4
42-49 Static-Stamped Gobo 5
50-57
Static-Stamped Gobo 6
58-65 Animation Position 1
66-73
Animation Position 2
74-81 Animation Position 3
82-89
Animation Position 4
90-97 Animation Position 5
98-105
Animation Position 6
106-112 Shake SLOW to FAST Static-Stamped Gobo 1
113-119
Shake SLOW to FAST Static-Stamped Gobo 2
120-126 Shake SLOW to FAST Static-Stamped Gobo 3
127-133
Shake SLOW to FAST Static-Stamped Gobo 4
134-140 Shake SLOW to FAST Static-Stamped Gobo 5
141-147
Shake SLOW to FAST Static-Stamped Gobo 6
148-154 Shake SLOW to FAST Animation Position 1
155-161
Shake SLOW to FAST Animation Position 2
162-168 Shake SLOW to FAST Animation Position 3
169-175
Shake SLOW to FAST Animation Position 4
176-182 Shake SLOW to FAST Animation Position 5
183-189
Shake SLOW to FAST Animation Position 6
190-221 *Clockwise Gobo Wheel Rotation from FAST to SLOW
222-223
NO Rotation
224-255 *Counterclockwise Gobo Wheel Rotation from SLOW to FAST
19
STATIC-STAMPED GOBOS, FINE INDEXING [GOBO WHEEL 2]
0-255 STATIC-STAMPED Gobo FINE Indexing
