38 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™
DMX Channel Values / Functions Version 1 - (37 DMX Channels)
Release Date: 2/9/2016 | Supports Software Versions: ≥ 1.5.2
Feature subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
8 10 15
ROTATING GOBOS, CONTINOUS ROTATION [GOBO WHEEL 1]
0-10
BEAM OPEN
11-21 SPOT OPEN
22-31
Rotating Gobo 1
32-41 Rotating Gobo 2
42-51
Rotating Gobo 3
52-61 Rotating Gobo 4
62-71
Rotating Gobo 5
72-81 Rotating Gobo 6
82-91
Rotating Gobo 7
92-101 Rotating Gobo 8
102-112
Gobo 1 Shake SLOW to FAST
113-123 Gobo 2 Shake SLOW to FAST
124-134
Gobo 3 Shake SLOW to FAST
135-145 Gobo 4 Shake SLOW to FAST
146-156
Gobo 5 Shake SLOW to FAST
157-167 Gobo 6 Shake SLOW to FAST
168-178
Gobo 7 Shake SLOW to FAST
179-189 Gobo 8 Shake SLOW to FAST
190-221
*Clockwise Gobo Wheel Rotation from FAST to SLOW
222-223 NO Rotation
224-255
*Counterclockwise Gobo Wheel Rotation from SLOW to FAST
9 11 16
ROTATING GOBOS, INDEX ROTATION [GOBO WHEEL 1]
0-127
ROTATING Gobo Indexing
128-189 *Clockwise Gobo Rotation from FAST TO SLOW
190-193
NO Rotation
194-255 *Counterclockwise Gobo Rotation from SLOW to FAST
17
ROTATING GOBOS, FINE INDEX ROTATION [GOBO WHEEL 1]
0-255 ROTATING Gobo FINE Indexing
