40 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™
DMX Channel Values / Functions Version 1 - (37 DMX Channels)
Release Date: 2/9/2016 | Supports Software Versions: ≥ 1.5.2
Feature subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
11 13 20
8-FACET ROTATING PRISM, LINEAR PRISM / GOBO MACROS
0-31
OPEN
32-79 8-FACET Prism
80-127
LINEAR Rotating Prism
128-135 Linear Prism / Gobo Macro 1
136-143
Linear Prism / Gobo Macro 2
144-151 Linear Prism / Gobo Macro 3
152-159
Linear Prism / Gobo Macro 4
160-167 Linear Prism / Gobo Macro 5
168-175
Linear Prism / Gobo Macro 6
176-183 Linear Prism / Gobo Macro 7
184-191
Linear Prism / Gobo Macro 8
192-199 Linear Prism / Gobo Macro 9
200-207
Linear Prism / Gobo Macro 10
208-215 Linear Prism / Gobo Macro 11
216-223
Linear Prism / Gobo Macro 12
224-231 Linear Prism / Gobo Macro 13
232-239
Linear Prism / Gobo Macro 14
240-247 Linear Prism / Gobo Macro 15
248-255
Linear Prism / Gobo Macro 16
12 14 21
8-FACET ROTATING PRISM, LINEAR PRISM / INDEX ROTATION
0-127
Prism Indexing
128-189 *Clockwise Linear Prism Rotation from FAST to SLOW
190-193
NO Rotation
194-255 *Counterclockwise Linear Prism Rotation from SLOW to FAST
22
8-FACET ROTATING PRISM, LINEAR PRISM / FINE INDEX ROTATION
0-255 Prism FINE Indexing
13 15 23
FOCUS
0-255 Continuous FOCUS Adjustment from NEAR to FAR
24
FOCUS FINE
0-255 Continuous FINE FOCUS Adjustment
14 16 25
MOTORIZED ZOOM
0-255 ZOOM Adjustment from SMALL to BIG
26
MOTORIZED ZOOM FINE
0-255 ZOOM FINE Adjustment
15 17 27
AUTO FOCUS
0-50 Auto Focus OFF
51-150
15m
151-255 20m
16 18 28
AUTO FOCUS FINE
0-255 Continuous FINE AUTO FOCUS Adjustment
