43 PLATINUM FLX™ User Manual
ELATION© PLATINUM FLX™
DMX Channel Values / Functions Version 1 - (37 DMX Channels)
Release Date: 2/9/2016 | Supports Software Versions: ≥ 1.5.2
Feature subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
24 26 37
SPECIAL FUNCTIONS
0-19
Color & Gobo Change Normal
20-29 Color Change to Any Position
30-39
Color & Static-Fixed Gobo Change to Any Position
40-59 Lamp ON
60-79
Lamp Switch OFF
80-84 ALL Motor Reset
85-87
PAN & TILT Motors Reset
88-90 COLORS Motor Reset
91-93
GOBOS Motor Reset
94-96 SHUTTER & DIMMER Motor Reset
97-99
OTHER Motor Reset
100-119 Internal Program 1 (Scene1-8)
120-139
Internal Program 2 (Scene 9-16)
140-159 Internal Program 3 (Scene 17-24)
160-179
Internal Program 4 (Scene 25-32)
180-199 Internal Program 5 (Scene 33-40)
200-219
Internal Program 6 (Scene 41-48)
220-239 Internal Program 7 (Scene 49-56)
240-255
Reserved
