20
Changing pre-set options
Out of Balance Recovery routine
When your Smart Drive™ is spinning it can sense
if the wash load is out of balance and will stop
and re-try spinning up to 3 times. If it still senses
an unbalanced load there are two options the
machine can take.
Automatic Recovery option
Your Smart Drive™ will try to automatically correct
the out of balance load. It will fill with water and
agitate to redistribute the load before trying to
spin up again.
Machine Stops option
Your Smart Drive™ will stop, give a short burst of
beeps every 5 seconds, and the
RINSE or SPIN light
will flash. You must redistribute the load more
evenly yourself. (Use this option if you wish to
conserve water).
Machine information
To find out the size of your machine, look on the back of your washer.
Specifications
Size Capacity Depth Width Height* Height (Lid Open)
Large 7.5 kg 650 mm 650 mm 1020 – 1050 mm 1410 – 1440 mm
Medium 6.5 kg 600 mm 600 mm 1020 – 1050 mm 1360 – 1390 mm
Compact 5.5 kg 560 mm 560 mm 1020 – 1050 mm 1320 – 1350 mm
Electrical Supply: 220 – 240V, 50Hz Sinusoidal, 165W
Inlet Water Pressure: Max. 1MPa (150 psi) Min. 34Pa (5 psi)
Inlet Water Flow Rate: Min. 3 litres/min
Standpipe Height: 850 – 1200 mm
Note: exact height of your washer is dependent on how far the feet are inserted onto the base
of the machine.
*Height is measured to the highest point on the console.
REGULAR
light on = automatic recovery
REGULAR
light off = machine stops
Fig.22 Adjusting Out of Balance Recovery routine
