ELBE 207-SM - Configuration Options; Trimmer functions; SW1 dip switch settings; SW2 dip switch settings

5
FOTO
It shows the output F
OTO.
AP (normally switched on, and if the photocells is engaged it switched off).
COSTA
It shows the output safety e
dge (normally switched on, and if the safety edge is engaged it switched off).
DL6
It shows the state of the setting.
Close the gate and check that LED stop, FOTO, FOTO. AP and COSTA are switched on; otherwise re-check the wiring.
4
Trimmer description.
AMP
Anti
-
cru
shing (obstacle dete
c
tion) adjustment, when the gate is moving.
Moving more to the
(
-
)
=
high
sensitivity. A small obstacle detected, adjusted according to the local norms of safety.
RALL.
Controls the speed during the slow part of the open
ing
and
closing. IE
.
just before
fully
open and closed.
Moving more to the (-) = slower. Moving more to the (-) = faster during this part.
VELOC.
This parameter
controls
the
overall main
speed
of the gate and
it should be adjusted
according to the local
norms of safety. Moving more to the (-) = slower. Moving more to the (-) = faster.
5
Dip Switches SW1 & SW2 features.
S
W
1
ON
OFF
1
Working
only
with 1 motor. Use input M1.
Working with 2 motors (M1 + M2).
2
Feature “close immediately” enable. When th
e gate is
opening, as soon as the photocells are disengaged, the
gate closes after 5 seconds.
Feature “close immediately” disable.
3
First push in an opposite way to release the electro
-
lock
(for gates with electro-lock only).
Push disable.
4
Extra push
while starting disable.
Extra push of 2 seconds while starting.
S
W
2
ON
OFF
1
Residential feature enable (while opening the control
panel does not accept any other Start impulse). When
gate has opened, a Start impulse closes the gate
without considering the automatic shutting set on it.
Residential feature disable. Step by step
feature enable also during opening.
Residential feature disable. Step by step feature
enable also during opening.
2
Enable the indicator of gate movement/position on
inputs 10-11 (LOCK).
Enable electro
-
lock on inputs 10
-
11 (LOCK ).
3
Enable use of resistive safety edge of 8K2.
Enable use of mechanical safety edge (N.C. Contact)
