4.0 Appropriate Usage / Operation Elements
Appropriate Usage
The instrument must only be used under the conditions and for the purpose for which it has been
constructed. Particular attention should be paid to the safety instructions, the technical specifications
relating to environmental conditions and the use of the instrument in dry surroundings.
4.1 Operation Elements
1. Mains Plug
2. Power/Backlight ON/OFF button
3. Push Button RCD Test
4. LCD
5. Capacitive Sensor
230V
N PE = L
TESTED NOT READY
TESTY2
Test
FI
mA
10mA
30mA
100mA
300mA
500mA
FI
OK OPEN
4
2
5
3
1
