4.4 Flexible flue parts dimensions continued…
1
Chimney Cover for Flexible Flue
Part
Part Code
D1
D2
L1
80mm
FLUEBRCTAA500
48
246
188
110mm
FLUECRCTAA500
72
246
188
2
Flex to Flex Adaptor
Part
Part Code
D1
L1
X1
80mm
FLUEBREFAA600
80
187
87
110mm
FLUECREFAA600
110
187
87
1
2
