elco Trigon XL Series User Manual

Technical data
10
Measure
unit
TRIGON XL
150 200 250
Nominal heat output at 80/60°C max/min
kW
142,3/31,3 190,4/42,0 237,6/47,0
Nominal heat output at 40/30°C max/min
kW 151,2/35,4 202,3/47,4 252,3/53,4
Nominal heat input Hi max/min
kW 145,0/32,2 194,0/43,1 242,0/48,4
Eciency at 80/60°C
% 98,2 98,2 98,2
Eciency at 40/30°C
% 104,3 104,3 104,2
Annual eciency (NNG 40/30°C)
%
110,4 110,4 110,4
Max. condensate ow
l/h 9,2 12,4 15,4
Gas consumpon G20 max/min (10,9 kWh/m
3
)
m
3
/h 13,3/3,0 17,8/4,0 22,2/4,4
Gas consumpon G25 max/min (8,34 kWh/m
3
)
m
3
/h
17,4/3,9 23,3/5,2 29,0/5,8
Gas consumpon G31 max/min (12,8 kWh/kg)
kg/h 11,3/2,5 15,2/3,4 18,9/3,8
Gas pressure G20
mbar
20
Gas pressure G25
mbar 25
Gas pressure G31
mbar
30/50
Maximum gas pressure
mbar 50
Max. temperature ue gas
°C 90
Flue gas temperature at 80/60°C max/min
°C 75/58 75/58 75/58
Flue gas temperature at 40/30°C max/min
°C
54/30 54/30 55/30
Flue gas quanty max/min H-gas
m
3
/h 188/43 251/57 313/64
CO2 level G20/G25 max/min
%
10,2/9,4 ±0,2 (Restricon type 570 delta max/min ≥0,8%)
CO2 level G31 max/min
% 11,9/10,0 ±0,2
NOx 80/60°C max/min
mg/kWh
38/19 38/19 36/18
CO 80/60°C max/min
mg/kWh 14/3 14/3 14/5
Max. permissible ue resistance max/min
Pa 200/10 200/10 200/10
Water volume
l 26 31 33
Water pressure max/min
bar 8/1
Max. water temperature (High limit thermostat)
°C 100
Maximum temperature setpoint
°C 90
Nominal water ow at dT=20K
m
3
/h 6,1 8,1 10,1
Hydraulic resistance at nominal water ow
kPa 11,2 26,8 31,2
Electrical connecon
V 230/400
Frequency
Hz 50
Mains connecon fuse
A 16
IP class
IP20
Power consumpon boiler max/min (excl. pump)
W 176/56 267/56 286/69
Power consumpon speed controlled pump (opt)
W
190/9 190/9 280/12
Weight (empty)
Kg 290 332 366
Sound Power Level (LWA)
dB
70,3 70,3 70,3
Ionisaon current average
μA 10,6/4,4
pH value condensate
-
3,2
CE cercaon code
- CE - 0063CQ3970
Water connecons
- R2” R2” R2”
Gas connecon
-
R1.1/2” R1.1/2” R1.1/2”
Flue gas connecon (DN)
mm 150 150 200
Air intake connecon (for room sealed use) (DN)
mm 130 130 130
Condensate connecon
mm 32
