Elcon MUX 2700 - 2108;64 HART D Solution

- 11 -
4.3 2108/64 HART D solution
IM-ENG-116/GB
Elcon I.S. Termination Panel
with pick-off for HART signals (example)
16 channels
16 channels
To RS485/RS232
converter
24 Vdc
General purpose
1-5 V HART signal inputs
(PHOENIX VARIOFACE style)
T.B. type 2108/64 HART D
(total 64 ch.)
16 channels
16 channels
FIG. 4
