- 14 -
IM-ENG-116/GB
6. MUX 2700 SPECIFICATIONS
N.B.: all values are typical unless otherwise specified.
6.1 General
6.2 Mechanical
Operating Temperature: 0 to 55 °C (32 to 131 °F)
Storage temperature: -20 to 70 °C (-4 to 158 °F)
Relative humidity (non condensing): 5 to 90 %
EMC: EN50081-2, EN50082-2
Isolation (Supply port to Signal port): 1400 Vac, rms
Isolation (Supply port to Serial port): 1400 Vac, rms
Isolation (Serial port to Signal port): 500 Vac, rms
CE marking carried
Dimensions: see drawing
Case: HiD style, Policarbonate
Mounting: plug-in on Termination Board (no tool required)
Protection class: IP30
Connectors: 2, plug-in, 40-poles miniature connectors
Hot-plug in: supported
Unit weight: about 140 grams
