• Address setting
The Mux 2700 module operates as a slave device on a multi-point RS-485 serial line. A unique address is therefore
to be specified for each Mux connected to the same serial line. To set the required address, use the first five swit-
ches according to the following table. Please note that the address 0 is reserved and is never to be used.
- 18 -
IM-ENG-116/GB
RS-485 ADDRESS
SW1 SW2 SW3 SW4 SW5
0 OFF OFF OFF OFF OFF
1 ON OFF OFF OFF OFF
2 OFF ON OFF OFF OFF
3 ON ON OFF OFF OFF
4 OFF OFF ON OFF OFF
5 ON OFF ON OFF OFF
6 OFF ON ON OFF OFF
7 ON ON ON OFF OFF
8 OFF OFF OFF ON OFF
9 ON OFF OFF ON OFF
10 OFF ON OFF ON OFF
11 ON ON OFF ON OFF
12 OFF OFF ON ON OFF
13 ON OFF ON ON OFF
14 OFF ON ON ON OFF
15 ON ON ON ON OFF
16 OFF OFF OFF OFF ON
17 ON OFF OFF OFF ON
18 OFF ON OFF OFF ON
19 ON ON OFF OFF ON
20 OFF OFF ON OFF ON
21 ON OFF ON OFF ON
22 OFF ON ON OFF ON
23 ON ON ON OFF ON
24 OFF OFF OFF ON ON
25 ON OFF OFF ON ON
26 OFF ON OFF ON ON
27 ON ON OFF ON ON
28 OFF OFF ON ON ON
29 ON OFF ON ON ON
30 OFF ON ON ON ON
31 ON ON ON ON ON
• Baud-rate setting
The next two switches permit to set the desired serial line baud-
rate. The same baud-rate must be set also on the RS-232/-RS-485
converter and on the PC RS-232 serial line. Please note that the
remaining SW6/7 configurations are reserved and never to be used.
RS 485 BAUD RATE
SW6
SW7
9600
OFF
OFF
19200
ON
OFF
• SW8 setting
The SW8 switch must be always set to OFF for normal operation. When set to ON, it enables the off-line self-test
mode.
