5.16 Return to default setting
In some cases it may be useful to set all functions back to the default settings of our
company. For this function dial:
  #   



#   
After 2 seconds the green light-emitting diode starts with fast flashing. The device
performs a RESET and start a new synchronisation with U interface. Please wait 20
seconds and then you can start with re-programming the device.
5.17 Configuration of the S/T-bus interface
It is possible to select between Short passive bus and Extended passive bus / Point-
to-Point connection (cf. figure 4).
Short passive bus:
  #       #   
Extended passive bus / Point to Point:
  #       #   
Default: Short passive bus
5.18 Incoming Call Management
For use of a PABX at analogue ports it is possible to set all incoming calls send only
to a/b1 for all incoming calls.
In case of compatible MSN and Terminal Type the function could be activated with:
Incoming calls are sent to both a/b1 and a/b2:
  #      #   
Incoming calls are sent only to a/b1. If a/b1 is busy the incoming call will be
sent to a/b2:
  #      #   
Note
 Default setting: Incoming calls are sent to both a/b1 and a/b2.
 For this service Call Waiting should be deactivated. Further should Clear Back
Time Delay switched off.
