8-34
HOW TO USE YOUR CARAVAN’S EQUIPMENT
Fig 3
Midi Heki Rooflight
(i) To open, push the large central button
(Fig 2).
(ii) Whilst depressed, slide the bar to the
desired position and locate into the stops
provided (Fig 3).
ROOFLIGHTS
Your caravan is fitted with at least one type of
the following roof lights:
The Omivent (12v) Rooflight
The Omivent is a double-glazed roof light
constructed from a synthetic ultra-violet
screened material. Its side-operating
mechanism allows a completely free central
opening with built-in fixed ventilation when
closed. It operates as an extractor fan and air
intake fan.
Please note: Do not change the direction of
the fan unless it has been switched off ‘O’
position and the blades have stopped
rotating.
Fig 2
Fig 1
