SPECIFICATIONS
MODEL
CP6220
CP6550
CP6770
CP6990
Measurement Ranges
100 mV/A – 10
mV/A
200 mV/A – 20
mV/A
500 mV/A – 50
mV/A
1 V/A – 100
mV/A
Current (DC + peak AC)
10 A – 100 A
5 A – 50 A
7 A – 70 A
4 A – 40 A
DC Measurement
Accuracy
±3% ±50 mA
@ 100 mV/A
(50 mA to 10 A
peak)
±4% ±50 mA
@ 10 mV/A
(500 mA to 40
A peak)
±15% max @
10 mV/A (40 A
peak to 100 A
peak)
<±3% ±30 mA
@ 200 mV/A
(30 mA to 5 A
peak)
±4% ±300 mA
@ 20 mV/A
(300 mA to 20
A peak)
±15% @ 200
mV/A (20 A
peak to 50 A
peak)
<±3% ±20 mA
@ 500 mV/A
(20 mA to 14 A
peak)
±4% ±200 mA
@ 50 mV/A
(200 mA to
100 A peak)
±15% @ 50
mV/A (100 A
peak to 140 A
peak)
<±3% ±10 mA
@ 1 V/A (10
mA to 8 A
peak)
±4% ±100 mA
@ 100 mV/A
(100 mA to 80
A peak)
Bandwidth
DC – 300 kHz
DC – 500 kHz
DC – 1 MHz
DC – 1.5 MHz
Phase Shift
See Graph
9(a)
See Graph
9(b)
See Graph
9(c)
See Graph
9(d)
Rise and Fall Time
1.2 µs (typ.)
0.7 µs (typ.)
0.35 µs (typ.)
0.23 µs (typ.)
Max. Working Voltage
600 VAC RMS CAT II / 300 VAC RMS CAT III
Max. Floating Voltage
600 VAC RMS CAT II / 300 VAC RMS CAT III
Battery Type
9 V Alkaline (NEDA 1604A, IEC 6LR61)
Typ. Battery Life
8 h
6 h
4 h
Operating Temp.
0 to 50°C (32 to 122°F)
Storage Temp.
-20 to 80°C (-4 to 176°F)
Max. Operating Humidity
0 to 95% (0 to 40°C; 32 to 104°F)
0 to 45% (40 to 50°C; 104 to 122°F)
Max. Cable Diameter
11 mm (0.43”)
10.3 mm (0.4”)
Dimensions
262 mm x 79 mm x 36 mm
(10.3 x 3.15 x 1.4”)
262 mm x 81 mm x 36 mm
(10.3 x 3.2 x 1.4”)
Weight
260 g w/o battery
310 g w/o battery
