Electra 7 - Page 14

10
Max Speed 6 km/h (3.75 mph)
Turning Radius 835 mm
Highest Obstacle Capability 40 mm (1.57")
Full overall length 975mm
Overall width 610mm
Stowage length 690mm
Stowage width 425mm
Stowage height 890mm
Rising / mm
Total mass 31.7kg
Mass of heaviest part 0.62kg(seat)
Pivot width 835mm
Reversing width 960mm
Turning diameter 1670mm
Ground clearance 70mm
Required width of angled corridor 960mm
Required doorway entry depth 1750mm
Required corridor width for side 960mm
Overall length with legrest 970mm
Overall width 610mm
Folded length 320mm
Folded width 610mm
Folded height 780mm
Total mass 26.5kg
Mass of the heaviest part 0.62kg
Static stability downhill
5°
Static stability uphill
8°
Static stability sideways
15°
Energy consumption 18km
Dynamic stability uphill
8°
Obstacle climbing 35mm
Maximum speed forward 6km/h
Minimum braking distance from 1000mm
