Why is my Electra WMZ 7 Air Conditioner not cooling or heating, and only the indoor fan works?
If your Electra Air Conditioner's indoor fan is running but there's no cooling or heating, the outdoor fan motor may be faulty, or another issue might have triggered the compressor overload protection. Try removing any obstructions blocking the outdoor fan. If that doesn't work, the P.C.B. may need replacement.
What to do if my Electra WMZ 7 is not cooling or heating, but the indoor fans are working?
If your Electra Air Conditioner's indoor fans are working, but there is no cooling or heating, the overload safety device on the compressor may have cut out due to low voltage or high temperature, the compressor run capacitor could be faulty, or the compressor windings may be shorted. Check for proper voltage, switch off the power, and try again after one hour. You may also need to replace the compressor capacitor or the compressor.
What to do if my Electra Air Conditioner is in heat mode but operating in cooling?
If your Electra Air Conditioner is set to heat mode but is operating in cooling, the RV coil may be faulty, or the valve may be stuck. Replace the RV coil or the reversing valve.
Why is my Electra Air Conditioner outdoor fan not working correctly?
If the outdoor fan on your Electra Air Conditioner isn't functioning properly, check the voltage between the outdoor fan terminals on the main P.C.B. If there's no voltage, replace the main P.C.B. If there is voltage, replace the capacitor or motor. Also, check and repair the electrical wiring between the indoor and outdoor units.
Why is my Electra Air Conditioner only running the indoor fan?
If your Electra Air Conditioner is only running the indoor fan, the run capacitor of the outdoor fan motor may be faulty, or the windings of the outdoor fan may be shorted. Replace the capacitor or the motor.
Why is my Electra WMZ 7 indoor fan not functioning correctly?
If the indoor fan of your Electra Air Conditioner isn't working correctly, check the voltage between the indoor fan terminals on the main P.C.B. If there is voltage, replace the capacitor or motor.
What to do if my Electra Air Conditioner compressor does not start up?
If the compressor on your Electra air conditioner isn't starting, begin by checking the voltage at the compressor terminals on the outdoor unit using an ammeter. If there's no voltage, the main P.C.B. may need to be replaced. If the voltage is low, repair the power supply. If the voltage is correct, consider replacing the capacitor or the compressor itself. If there is no voltage, repair electrical wiring between indoor and outdoor units.
What to do if water accumulates and overflows from my Electra WMZ 7 Air Conditioner indoor unit?
If water is accumulating and overflowing from the indoor unit of your Electra Air Conditioner, the drain tube or spout of the drain pan is likely clogged. Disassemble the plastic drain tube from the spout of the indoor unit drain pan to clear the blockage.
Why is my Electra WMZ 7 Air Conditioner only running the indoor fan and compressor?
If your Electra Air Conditioner is only running the indoor fan and compressor, the outdoor fan may be blocked. Remove any obstructions.
What to do if my Electra WMZ 7 has freeze-up of outdoor coil in heating mode?
If you notice freeze-up of the outdoor coil in heating mode on your Electra Air Conditioner, resulting in a poor heating effect while the indoor fan operates, the outdoor thermistor could be faulty, the control cable might be damaged, the outdoor temperature may be below design conditions, or the outdoor unit air outlet might be blocked. Replace the thermistor or repair the control cable. If the outdoor temperature is too low, shut the unit off as it cannot work properly. Also, ensure there are no obstructions blocking the outdoor unit air outlet.
General| Brand | Electra |
|---|---|
| Model | WMZ 7 |
| Category | Air Conditioner |
| Language | English |
Overview of the WMZ split wall mounted range, including cooling and heat pump models.
Lists the key features of the WMZ indoor units, including R22/R407C compatibility and advanced controls.
Details the components and characteristics of the indoor unit.
Describes the different types of air filters available for the WMZ series.
Explains the control system, including the indoor controller and remote control.
Describes the outdoor unit, its installation, and components.
Information on tubing connections for the WMZ series units.
Details available accessories like the All Season Kit (ASK) and remote controls.
Lists the documentation included with each unit.
Table showing compatible indoor and outdoor unit models.
Product data for WMZ-7 GCZ-7 with R407C, detailing specifications for indoor and outdoor units.
Product data for WMZ-9 GCZ-9 with R22, including technical specifications.
Product data for WMZ-12 GCZ-12, covering cooling and heating specifications.
Product data for WMZ-17 GCZ-17, detailing performance and technical specifications.
Product data for WMZ-22 GCZ-22, including performance metrics and unit dimensions.
Product data for WMZ-7 GCZ-7 with R22, covering technical specifications and performance.
Product data for WMZ-9 GCZ-9 with R22, detailing performance figures.
Product data for WMZ-12 GCZ-12 with R22, including specifications for cooling and heating.
Product data for WMZ-17 GCZ-17 with R22, covering performance and electrical details.
Product data for WMZ-22 GCZ-22 with R22, detailing operational parameters.
Specifies the operating limits for cooling and heating for R407C and R22 models.
Provides outline dimensions and installation details for WMZ 7, 9, and 12 indoor units.
Shows outline dimensions for GCZ 7, 9, and 12 outdoor units.
Displays outline dimensions for the GCZ 17 outdoor unit.
Presents outline dimensions for the GCZ 22 outdoor unit.
Covers cooling and heating performance data for WMZ/GCZ R22 models.
Covers cooling and heating performance data for WMZ/GCZ R407C models.
Factors for correcting capacity based on tubing length for cooling and heating.
Cooling pressure curves showing discharge and suction pressure against outdoor temperature.
Heating pressure curves illustrating discharge and suction pressure versus outdoor temperature.
Explains sound pressure level measurement methods for different unit types.
Displays sound pressure level spectra for WMZ 7 and WMZ 9 indoor units.
Provides sound pressure and sound power levels for outdoor units.
Sound pressure level spectra for cooling and heating modes.
Electrical data for single-phase WMZ units, including power supply and wiring.
Wiring diagram for WMZ 7, 9, and 12 indoor units.
Wiring diagram for WMZ 17 and 22 indoor units.
Wiring diagram for GCZ 7, 9, 12, and 17 outdoor units.
Wiring diagram for the GCZ 22 outdoor unit.
Illustrates electrical connections between indoor and outdoor WMZ units.
Refrigeration diagrams for heat pump models (WMZ 7,9 RC R407C and WMZ 9,12 RC R22).
Refrigeration diagrams for heat pump models WMZ12,17,22 RC R407C and WMZ 7, 17, 22 R22.
Refrigeration diagrams for cooling-only models WMZ 7, 9, 12, 17, 22 RC R407C and R22.
Table of tube sizes and corresponding tightening torques for unions and valve caps.
Covers electronic control, introduction, jumper settings, legend, and PCB controller.
Details general functions, cooling, heating, dry modes, timer, forced, and sleep operations.
Covers cooling/heating protections, deicing, and thermistor fault handling.
Step-by-step guide for self-tests via jumper, remote control, LEDs, relays, and memory.
Explains the functions of the stand-by indicator, operation indicator, and mode button.
Details clock random delay and setting procedures.
Exploded views and spare parts lists for R22/R407C models.
Covers exploded views and parts for WMZ 7, 9, 12, 17, 22 indoor units.
Covers exploded views and parts for GCZ 7, 9, 12, 17, 22 ST R22 outdoor units.
Covers exploded views and parts for GCZ 17, 22 ST R407C outdoor units.
Covers exploded views and parts for GCZ 7, 9, 12, 17, 22 RC R22/R407C outdoor units.
Information on the All Season Kit (ASK) for low-temperature cooling.
Lists installation and operation manuals for WMZ 7, 9, 12 and WMZ 17, 22.
